Tecna Hammer

€3,267

Delivery not available to your location

This item cannot be shipped to your selected delivery location. Please choose a different delivery address or check other available sellers.

Finance the purchase of this equipment, another one from our website, or even one found elsewhere. We analyze and compare the best financing options from over 30 financial institutions to help you secure the most suitable one.

Amount

Duration

Total to pay

€3,601.20 VAT incl.

Interest

€334.20 VAT incl. (TAE 3.97%)

You will pay per month

€60.02 VAT incl.

Example of financing with Plettora for an initial amount of €3,267 over 60 months, with payments beginning 30 days after the application. 60 monthly payments of €60.02 are required. Arrangement fee: €0. TIN: 3.90%. TAE: 3.97%. Total amount to pay: €3,601.20. Non-binding offer subject to approval by Plettora.

Duration

Residual rate

Residual value

€270

Amount to be financed

€3,267 VAT incl.

Interest

€353.70 VAT incl.

Commission

€16.34 VAT incl.

Total expenses

€370.04 VAT incl. (TAE 4.17%)

Total to pay

€3,637.04 VAT incl.

You will pay per month

€54.90 VAT incl.

Example of financing with Plettora for an asset valued €2,700 (excluding VAT) over 60 months, with payments beginning 30 days after the application. A down payment of €71.24 is required to be paid at the time of the transaction, which consists of a monthly payment amount and all the commissions. The amount to be financed is the difference between the asset value (including VAT) and the sum of the down payment and the optional residual payment at the end. 60 monthly payments of €54.90 are required. Total commision: €16.34. TIN: 3.9%. TAE: 4.17%. Total amount to pay: €3,637.04, with an optional residual payment of €326.70 at the end to take the ownership of the asset. Non-binding offer subject to approval by Plettora.

Hydraulic Hammer TECNA T160H

The TECNA T160H HAMMER is a hydraulic hammer specifically designed for use on mini excavators weighing between 1.8 and 3 tons. This efficiently designed tool enhances the performance and effectiveness of your excavation projects. Below are the fundamental technical specifications:

Operating weight: 160 kg (352.7 lbs)
Tool diameter: 48 mm (1.89 in)
Oil flow: 25 to 45 l/min (7 to 12 GPM)
Working pressure: 100 to 140 bar (1450 to 2031 PSI)
Relief pressure (set on the excavator): 180 bar (2611 PSI)
Maximum back pressure: 20 bar (290 PSI)
Maximum input power: 8 kW (10.7 HP)
Impact energy class: 393 J (290 ft-lbs)
Impact frequency: 700 to 1100 blows per minute (BPM)
Maximum hydraulic oil temperature: 80 °C (176 °F)
Minimum recommended size for the inlet line: 12 mm (0.47 in)
Minimum recommended size for the return line: 14 mm (0.55 in)
Minimum recommended length of flexible hoses: 1400 mm (55.1 in)
Hose connection on the return line: 1/2" G
Hose connection on the inlet line: 1/2" G

For more detailed information, it is advisable to consult the user and maintenance manual for the TECNA T series hydraulic hammers, which is available in Spanish. The official TECNA website also provides additional information about its products, including the T series hydraulic hammers.

For a more comprehensive description of the T160H model, you can review the TECNA Group S.r.l. catalog, which offers information on hydraulic hammers intended for excavators.

These resources provide comprehensive and up-to-date information about the TECNA T160H hydraulic hammer.
